Type 2 Bracket

These flat-packed, self assembly brackets provide a professional finish to the installation of wall mounted outdoor condensing units and air source heat pumps. The Type 2 Brackets have a crossbar allowing the uprights to be spaced exactly as required, and include wall spacers to help level the unit on uneven walls. All components receive a powder coating, with a scratch resistant, textured finish in a colour (RAL 7032) to match most brands of condensing units and domestic air source heat pumps.

Features:

• Integral spirit level for easier, correct installation
• Uprights mount anywhere on the crossbar which enables the arm span to be adjusted easily
• Adjustable wall spacers to level the arms
• Safe working load up to 250kg
• Suitable to match most brands of condensing units and domestic air source heat pumps
• Extra long arms**
• Textured finish in (RAL 7032)

** Brackets available for larger condensing units with extra long arms of up to 780mm
